1、供水压力低,节能;
2、布水均匀性能好。
型号 | 孔数 | 外形尺寸 | 安装尺寸 | |||||
A | B | C | D | G | F | E | ||
1.5 | 4 | 125 | 80 | ø30 | 56 | 2X5+字槽 | G1/2寸(Inch) | G1.5寸(Inch) |
2 | 4 | 142 | 95 | ø35 | 68 | 2X5+字槽 | G3/4寸(Inch) | G2寸(Inch) |
2 | 6 | 142 | 95 | ø35 | 68 | 2X5+字槽 | G3/4寸(Inch) | G2寸(Inch) |
2.5 | 4 | 165 | 120 | ø45 | 87 | 2X5+字槽 | G1寸(Inch) | G2.5寸(Inch) |
3 | 4 | 182 | 137 | ø48 | 101 | 2X5+字槽 | G1/2寸/ø49 | G3寸/ø90 |
3 | 6 | 182 | 137 | ø58 | 101 | 2X5+字槽 | G1/2寸(Inch) | G3寸(Inch) |
4 | 6 | 270 | 168 | ø58 | 124 | ø22 | G1/2寸(Inch) | G4寸(Inch) |
4 | 4 | 320 | 200 | ø58 | ø136 | ø22 | ø61 | G4寸/ø115 |
5 | 4 | 350 | 240 | ø73 | ø160 | ø22 | ø77 | G5寸/ø141 |
5 | 6 | 340 | 210 | ø89 | ø160 | ø22 | ø61 | G5寸/ø141 |
6 | 6 | 370 | 230 | ø80 | ø185 | ø22 | ø77 | G6寸/ø167 |
6 | 4 | 380 | 260 | ø91 | ø192 | ø22 | ø90 | G6寸/ø167 |
8 | 6 | 370 | 310 | ø104 | ø245 | ø22 | ø90 | G8寸/ø218 |
10 | 8 | 400 | 380 | ø104 | ø305 | ø29 | ø90 | G10寸/ø269 |
12 | 10 | 530 | 510 | ø131 | ø340 | ø29 | ø115 | G12寸/ø320 |
